Data Sheet

• CPU-Onboard Intel Atom D2550
• BIOS AMI 16Mbit SPI BIOS
• System Chipset Intel ICH10-R
• I/O Chip ITE8781 + FINTEK1214
• Storage 16/32 GB SSD
• Watchdog Timer H/W Reset : 1 to 255 sec/min per step
• H/W Status Monitor Monitoring System Temperature, Voltage with Auto Throttling Control
• RAM 2 GB
• Ethernet 2 x Realtek 8111E Gigabit Ethernet
• Power Requirement DC +12V
• Power Type AT / ATX Mode (Selectable by Jumper)
• Operation Temperature 0 ~ 60°C (32 ~ 140°F)
• Storage Temperature - 40 ~ 75°C (-40 ~ 167°F)
• Operating Humidity 0 ~ 90% Relative Humidity, Non-condensing
• Size ( L x W ) 6.69” x 6.69” (170mm x 170mm)
• Weight 0.88lbs (0.4Kg)
